APC Back-UPS Connect 12Vdc 36W (Lithium-ion Power Supply)
The APC Back-UPS Connect 12Vdc 36W is a compact, high-efficiency mini UPS designed specifically to keep essential 12V DC network and smart devices online during electrical outages. Engineered to support Wi-Fi routers, modems, IP security cameras, and smart home assistants, this ultra-lightweight power supply prevents internet disconnections and maintains home automation reliability when main power drops.
Powered by advanced internal Lithium-ion battery technology, it provides high energy density, long operational battery life, and compact portability compared to traditional lead-acid units. Featuring simple plug-in installation, it acts as a reliable inline backup system for everyday 12V electronics.
Key Features & Highlights
- Lithium-Ion Battery Technology: High-density Li-Ion cell design ensures long lifespan, fast power delivery, and lightweight portability.
- 12V DC Output & 36W Capacity: Engineered for 12V network gear, security cameras, smart home hubs, and wireless routers.
- Uninterrupted Network Connectivity: Guarantees online connectivity during blackouts without network dropouts or router restarts.
- Ultra-Compact Plug-In Design: Sleek white casing with a minimal footprint for easy mounting directly near equipment.
- Energy Efficient Operation: Low tare power loss (2W) ensures high operational efficiency during everyday standby usage.
- CE Certified Protection: Fully compliant with EN/IEC international standards for electrical and electromagnetic safety.
Detailed Product Specifications
1. Electrical Input & Output Performance
| Attribute | Specification Details |
|---|---|
| Brand / Line | APC Back-UPS Connect |
| Product Type | 12V DC Mini UPS / Power Supply |
| Max Output Power Rating | 36 Watts |
| Main Input / Output Voltage | 12V DC (Single Phase) |
| Mounting Mode / Type | Plug-in / Non-Rackmount |
| Tare Power Loss | 2 Watts |
2. Battery System & Physical Dimensions
| Attribute | Specification Details |
|---|---|
| Battery Chemistry | Lithium-ion (Li-Ion) Internal Battery |
| Battery Recharge Time | 9 Hours |
| Removable Battery | Yes |
| Product Net Weight | 0.3 kg (0.66 lbs) |
| Dimensions (H x W x D) | 25 mm x 99 mm x 109 mm (0.98″ x 3.9″ x 4.29″) |
| Color / Casing | White / Ultra-Compact Form Factor |
3. Environmental, Compliance & Packaging Specs
| Attribute | Specification Details |
|---|---|
| Operating Temperature / Humidity | 0 to 40 °C (32 to 104 °F) | 0 to 95% Relative Humidity |
| Storage Range | -10 to 50 °C | Altitude 0 to 5000 m |
| IP Protection Rating | < IP20 |
| Standards & Certifications | CE Certified | EN/IEC 62368-1, EN/IEC 61000-4-2, EN/IEC 61000-4-8 |
| Package 1 Weight & Dimensions | 366 g | 3.3 cm H x 11.5 cm W x 16.3 cm L |
| Manufacturer Warranty | 24 Months (2 Years) |
Package Contents
- 1 x APC Back-UPS Connect 12Vdc 36W (Lithium-ion)
- 1 x User Manual & Setup Documentation
